Scale Master Pro XE Digital Plan Measure Device - Model 6138

Digital Plan / Blueprint Measuring Device

The Scale Master Pro XE is a digital plan-measuring tool designed for architects and estimators who perform material takeoffs from blueprints, construction drawings, and site plans. At The Contractors Site, we supply the Scale Master Pro XE for Ontario estimating professionals who need fast, accurate linear and area measurements directly from scaled drawings without manual calculation.

Specifically designed to simplify takeoffs from architectural and engineering drawings, the Scale Master Pro XE finds linear measurements of any shape, as well as rectangular areas and volumes, and it converts between scales and dimensions.

It comes with 91 built-in scales and 10 custom scales for maximum versatility, enabling you to define any scale, even from plans that have been reduced, enlarged, or are just out of scale. You can easily store the new scale permanently in the device for future use.

Other features include two built-in memories; dedicated length, width, and height keys; a push-button counter to keep track of items while rolling; a switch for locking in mode, scale, and units while rolling; and a subtract key that allows you to deduct rolled distances. Easy to learn and use, the Scale Master Pro XE will save you time and reduce errors on your estimates and bids.

For contractors, estimators, engineers, landscapers, pipeline builders, excavators, HVAC contractors, pavers, electrical contractors - anyone needing fast, accurate takeoffs from plans and blueprints.

Measure Directly from the Blueprint

The Scale Master Pro XE rolls along the surface of a blueprint or plan drawing and calculates the actual dimension, automatically scaling the wheel travel to the drawing scale you've selected. What used to require a scale rule, a calculator, and careful addition is completed in a single pass of the measuring wheel along the drawn line. For estimators doing takeoffs from multiple drawings, the time savings per measurement is significant.

Details:

• Get instant linear, rectangular area and volume takeoffs; use it like a pen - just roll and measure
• Convert between scales and dimensions
• 10 user-set custom scales. Calibrates to any plan and then stores that scale for future use. Perfect for scaling faxed or out-of-scale plans.
• Calculate rectangular areas/volumes (LxWxH). Roll and enter the length of the room, then width and instantly calculate square footage.

• Multiple dimensional units for versatility; select the measurement units you use: decimal feet, feet-inches, decimal inches, yards, millimetres, meters, kilometres - including square and cubic formats
• Subtract and Counter feature lets you subtract if you roll too far. Also lets you count items (e.g., studs, outlets, etc.) and accumulate in memory.
• Easy-to-read dual display shows your measurement in feet/inches or metric

Includes:

• Hard cover protective case
• Complete User's Guide
• Two long-life CR2032 lithium batteries
• One-year warranty

Tech Specs

Size: 7.3" x 1.9" x 0.6" (186 x 47 x 15 mm)

Wheel Resolution: 0.025" (0.635 mm)

Wheel Composition: Celcon Polymer

Weight (product only with battery): 2.1 oz. (60 g)

Power: Two 3-volt lithium (CR-2032) batteries (included)

Display Type: LCD segment; 7-digit main display, 3-digit count, 5-digit scale display, with annunciator legends

Display Dimensions: Upper: 0.62 x 1.22" (15.8 x 31 mm)
Lower: 0.79 x 1.22" (20 x 31 mm)

Accuracy: Mechanical accuracy 99.8%. Users should allow for 2-4% variance for start/stop points and rolling surfaces.
